SD9N Bulldozer
SD9 bulldozer: semi-rigid elasticity suspending,
hydraulic-mechanical transmission, elevated sprocket track type, wholly
hydraulic operation, pilot hydraulic controlling blade operation, modular
designing components easily for maintaining, portable laborsaving nicety
man-machine designing controlling system, electric monitoring, ROPS cabin, many
optional equipments, broadly used in transport, desert, oil field, power
station, mine, swamp etc. large-scale stone construction. You can select original
American Cummins engine, emission standard meet with Tire 3 with lower fuel
consumption and stronger power output.
|
SPECIFICATION |
||||||
|
Operation weight (Kg) ( including ripper) |
48880 |
|||||
|
Operation weight (Kg) (not including ripper) |
44580 |
|||||
|
Ground pressure(KPa) |
112 |
|||||
|
Track gauge(mm)
|
2250 |
|||||
|
Gradient |
30°/25° |
|||||
|
Min. ground clearance (mm) |
517 |
|||||
|
Dozing capacity (m³) |
13.5 |
|||||
|
Blade width (mm) |
4314 |
|||||
|
Max. digging depth (mm) |
614 |
|||||
|
Overall dimensions (mm)
|
8478×4314×3970 |
|||||
|
Engine |
||||||
|
Type |
KTA19-C525S10 |
|||||
|
Rated revolution (rpm) |
1800 |
|||||
|
Rated power (KW) |
316/430 |
|||||
|
Torque storage
coefficient |
18% |
|||||
|
Undercarriage system |
||||||
|
Type |
The track is triangle shape. The sprocket is elevated elastic
suspended. |
|||||
|
Number of track rollers (each side) |
8 |
|||||
|
Pitch (mm)
|
240 |
|||||
|
Width of shoe (mm) |
610 |
|||||
|
Gear |
1st |
2nd |
3rd |
|||
|
Forward
(Km/h) |
0-3.9 |
0-6.7 |
0-12.2 |
|||
|
Backward (Km/h) |
0-4.8 |
0-8.5 |
0-15.1 |
|||
|
Implement hydraulic system |
||||||
|
Max. system pressure (MPa) |
18.3 |
|||||
|
Pump type |
Double vane pump |
|||||
|
System output（L/min） |
358 |
|||||
|
Driving system |
||||||
|
Torque converter |
Torque converter is power separating
hydraulic-mechanic type |
|||||
|
Transmission |
Planetary, power shift transmission With three
speeds forward and three speeds reverse, speeds and direction can be quickly
shift |
|||||
|
Steering clutch |
The steering clutch is hydraulic pressed, usually
separated clutch. |
|||||
|
Braking clutch
|
The braking clutch is pressed by spring,
separated hydraulic, meshed type. |
|||||
|
Final drive |
The final drive is two-stage planetary reduction
gear mechanism, splash lubrication.
|
|||||
