API 6A Well head casing head, Casing hesd

Casing Head API 6A

Casing head is used to fix the drilling well and connect the casing string under the well. It can reliably seal and control the annular spaces between pipes, and it is an important part of Wellhead. Casing head is designed with a 45° Circular bead, used to support the weight of casing string transmitted by casing hanger, and BT type secondary seal can be used for the bottom.

Rated working pressure: 2000psi-20000psi
Rated working temperature: -46º C-121º C
Working medium: Oil, gas, mud and water
Material class: AA-ff
Product specification level: Psl1-3
Performance requirement level: PR1

Parts:

1 piece Casing Head Housing API 3000Psi WP top flange 13.5/8" x 13.3/8"BTC Female thread Bottom w/ two 2.1/16” studded Outlets where bolts are ready installed.
1 piece Casing Hanger, C-22, 13.5/8" X 9.5/8" ( Slip and seal type)
2 pieces GATE VALVE 3K 2.1/16" flange
2 pieces BULL PLG XH, 2" LP, Tapped ½” NPT
2 pieces Nipple XXH, 2” x 8” long
2 pieces Needle Valve, MFA, ½” NPT
2 pieces Pressure Gauge 0-3K w/ 4.1/2” Face
BLT+N A193-B7 UNC SUITABLE BOLTS +NUTS (LG cadmium plated, ASTM A194, Grade 2H)
GSKT RJ SS304 OCT.PE SUITABLE GSKT.

Packaging

After Sales Warranty
