Copper Conductor LSF insulated Wires to BS 7211 (HO7Z-R with Stranded Conductor) 450 - 750 volts

Article No
5EWC0314349
Supplier ID
A01
Supply Capability:
Depends on the sizes
Lead time:
4 weeks
Trade Terms:
Ex UAE warehouse
Payment Terms :
TT in Advance
Certification :
BS 7211
Origin :
AE
Ref Price Get Latest Price
Enquire Now Add to favorites

LSHF (Low smoke halogen free) material is used in filling & jacketing of cables with special characteristics of non toxic emissions.LSHF (Low smoke halogen free) insulation grade for 450/750 V wires is produced as well.

For internal wiring of equipment rated voltage up to 1000 V AC and up to 750 V DC to earth.


Item Code


Nominal Cross Section

Conductor


Insulation Thickness


Overall Diameter


Weight of Finished Cable Approx


Maximum DC Resistance at 20°C


Standard Packing Length

Number of Wires in Conductor

Diameter of Conductor Approx.



mm²

No

mm

mm

mm

Kg/Km

Ohm/Km

M±5%

0C063104xx

1x1.5

7

1.50

0.7

3.0

20

12.1

100 C

0C063105xx

1x2.5

7

12.00

0.8

3.7

35

7.41

100 C

0C063106xx

1x4

7

2.60

0.8

4.2

50

4.61

100 C

0C063107xx

1x6

7

3.10

0.8

4.8

70

3.08

100 C

0C063108xx

1x10

7

4.00

1.0

6.0

115

1.83

100 C

0C063109xx

1x16

7

5.00

1.0

7.0

170

1.15

100 C

0C063110xx

1x25

7

6.30

1.2

8.7

265

0.727

Packaging

In rolls

After Sales Warranty

1 year
