CNC Belt Turcite Sheet

Supply Capability:
10000
Lead time:
30
Trade Terms:
Payment Terms :
TT in Advance
Certification :
Origin :
Hengshui Aohong Special Glass Manufacturing Co., Ltd
Ref Price
USD 100 /Acres
100 (Min. Order Quantity)
Enquire Now Add to favorites

CNC Belt turcite sheet ---Slydway Linear Bearing Strip

Turcite sheet is kind of composite material of PTFE with the polymer as the base a high performance linear bearing strip for use on linear bearing application of the machine guideways tools and other gibs way applications.

turcite sheet

Guideways on CNC machine tools ensure the exact direction of motion of components such as slides, sleeves, quills,plungers, etc. At the same time, guideways must bear the weight of the guided components and workpieces and absorb the machining forces without deformation.

Specifications:

  • Thickness: 0.5-6.0mm
  • Common width: 300-305mm
  • Length: Customizable to your specifications

These places critical demands on the machine tool guideways:

Turcit b slydway provides low friction, stick-slip-free

operation, long life and minimum wear.

It is installed using a two-part epoxy resin adhesive after cleaning and degreasing the bare metal surface thoroughly.

The seal is dimensionally stable, maintenance-free and can be operated with or

without lubrication.

Advantages:

  • Low friction without stick slip for positional accuracy at different velocities, especially low speeds
  • Low coefficient of friction in intermittent lack of lubrications
  • Chemical resistant to a broad range of lubricants for extended product life
  • Minimal abrasion of hardware, preventing damage to counter surfaces
  • High wear resistance for extended product life
MaterialPTFE+bronze
Colourgreen
Density2.7-3.2
Coefficient of linear expansion (40-120°C)7.5
Tensile strength (Mpa)14
Elongation (%)150
Compressive strength (Mpa)28-38
Bending strength (Mpa)23-29
Non-notched impact strength(KJ/m2)>14
Friction loss performance (dry friction)Friction coefficient (μ)0.16-0.23
trace Width of friction(m)<7.5
friction loss(mm3)6.5-11.2

Packaging

After Sales Warranty

turcite sheet designs

What is a CNC machine Slideway turcite ?

CNC machine Slideway turcite sheet is a proprietary formulation of PTFE material impregnated with bronze and friction reducing additives.

What does a Turcite Slideway do?

1. Reduces friction and wear

2. Increases accuracy

3. Extends machine life

4. Saves energy

5. Reduces damage caused by mechanical problems
