PE Jaw Crusher
The PE series jaw crusher is usually used in the production lines of various hardest stones, ore crushing and recycle materials as primary and secondary stage crusher. DSMAC jaw crusher is designed for materials whose compression strength is no more than 320Mpa. It simulates the movement of animal’s two jaws, crushing the materials through the opening and closing of two jaw plates (moving jaw and fixed jaw).
Engineered for toughest material, Dingsheng® PE Series jaw crushers offer an extensive range of models for static and mobile jaw crushing applications. Our jaw crushers are widely used in quarry and mining plants. Our designs include small unit with inlet opening from 200mm x 400mm to large sized unit with 1500mm x 1800mm inlet opening giving 1300 tons per hour capacity.
| Model | Max. feed size (mm) | Max. feed capacity (t/h) | CSS** (mm) | Power (kw) | Weight (t) |
| PE500x750 | 425 | 110 | 50-100 | 45-55 | 12 |
| PE600x900 | 480 | 180 | 65-160 | 55-75 | 17 |
| PE750x1060 | 630 | 320 | 80-140 | 90-110 | 29 |
| PE900x1200 | 750 | 450 | 95-165 | 110-132 | 58 |
| PE1000x1200 | 850 | 560 | 200-300 | 110-160 | 69 |
| PE1200x1500 | 1020 | 800 | 150-300 | 160-220 | 95 |
| PE1500x1800 | 1200 | 1050 | 210-360 | 280 | 130 |
Note: Any change of technical data shall not be advised additionally.
Packaging
After Sales Warranty
Steel box or wooden package, 12 months warranty
