220vdc electric valve actuator dkj-8100cx dkj-7100cx dkj-6100cx dkj-6100acx

Brand
FRY
Article No
S12292864100
Supplier ID
S0060
Supply Capability:
300 SETS PER MONTH
Lead time:
15 DAYS
Trade Terms:
Payment Terms :
TT in Advance
Certification :
Origin :
TIANJIN CHINA
Ref Price
USD 500 /Sets
1 (Min. Order Quantity)
Enquire Now Add to favorites


DKJ electric actuator, an execution unit in DDZ type electronic unit combined instrument, accepts signals from a regulating unit (or computer) and automatically controls the actuator to complete regulating tasks. It is widely applied to power stations chemical, petroleum, metallurgy, building materials,heat supply, water treatment and other industries.

DKJ type electric actuator with various electric Manipulators can achieve undisturbed switching of"Manual-Automatic of the regulating system for remote manual operation on an object to be regulated in a timely manner.

All the actuator position transmitters produced by our company adopt the latest sensory packages be reference to the latest circuits of foreign companies, integrating power transformer, rectification, voltage stabilization, power amplification and constant current, the fabricated module (M) makes the reliability and stability of the actuator higher, so as to make the system more secure and reliable.


Mode

Output Torque

Nm

Travel time

S

Weight

kg

0~10mA

4~20mA

DKJ-210

DKJ-2100

100

25

30

DKJ-310

DKJ-3100

250

45

DKJ-410

DKJ-4100

600

75

DKJ-510

DKJ-5100

1600

125

DKJ-610A

DKJ-6100A

2500

40

130

DKJ-610

DKJ-6100

4000

60

175

DKJ-710

DKJ-7100

6000

60

230

DKJ-810

DKJ-8100

10000

100

230









1.The product has reasonable structure, strict production technology and quality management, so that the high reliability of the actuator is ensured, with Mean Time Between Failure (MTBF) >25000 hours.

2.The position transmitter switching circuit has high induced voltage resistance, and its performance exceeds similar products at home and abroad.

3.The travel control cams can be independently adjusted without interference, so that the adjustment is easy and convenient.

4.The AC single-phase motor is used in the high torque actuator to bring convenience to the use of the automatic control system.

5.The motor brake wheel made of special materials has the characteristics of reliable braking, long service life, and superior to similar products.


Input signals

Type II:0-10mA,DC;Type III:4-20mA,DC

Input channel

3

Input channel impedance

Type II :200Ω;Type III:250Ω

Basic error

±2.5%(dead band:≤3% Return difference: 1.5%)

Damping characteristic

≤ a half and three cycles

Voltage of the power supply

220V(+10%,~15%) frequency: 50HZ

Temperature of the operating environment

Actuator: -10~+55℃ or -25~+70℃;amplifier:0~+50℃

Relative humidity of the operating environment

Actuator:≤95%;amplifier:10%~70%

The following letters represent the different control features and conjunctive modes when combine with the prefix DKJ, SKJ and ZKJ of quarter-turn electric actuator.

1. M type means switch-type module actuation.

2. D type and DY-JT type means electronic type(regulating) module actuation.

3. Z type means direct-connected actuation. ZM type is switch-type direct-connected actuation. ZD type is electronic direct-connected actuation.

4. B type means explosive-proof actuation. BM type is switch-type explosive-proof actuation. BD type is electronic explosive-proof actuation.

5. F type means electronic(regulating) module actuation.

6. Y type means electronic(regulating) module actuation.

7. EX type means explosive-proof or intelligent digital display regulating actuation.

8. CX type means the actuator has signal feedback DC 4-20mA with electric limit switch indication.
