Corrugated Sheet Roll Forming Machine
Corrugated Sheet Roll Forming Machine is used to produce the Metal tile which is used in roof,it is widely used in the world.We also support customization according to customer's request.
Item | Name | Specifications |
1 | Raw material | PPGI,Galvanized steel,Stainless steel |
2 | Raw material thickness | 0.3-0.8mm |
3 | Decoiler | Manual/Hydraulic decoiler |
4 | Roller station | 15 station(according to profile drawing) |
5 | Roller material | 45# steel with quenched treatment |
6 | Shaft diameter | 80mm |
7 | Shaft material | 45# steel with tempered |
8 | Transmission | by chain |
9 | Motor power | 5.5kw |
10 | Machine frame | 350H steel welded |
11 | Cutting type | Electric motor cutting |
12 | Hydraulic power | 5.5kw |
13 | Cutting blade material | Cr12 with quenched treatment |
14 | Cutting tolerance | +/-1mm |
15 | Control system | PLC |
16 | Brand | PLC:Delta/Siemens/Mitsubishi Touch screen:Delta/Siemens/Mitsubishi Encoder:Omron |
Packaging
After Sales Warranty
Packing:Anti-dust oil spray on the rollers and blades,plastic wrap for the whole machine
Warranty:One year,and parts is broken(not human being reason) we will replace new one for customer
Aftersales:We will support technical support for the whole life of the machine.
