Dredger Sand Tailing Industrial Trash Discharge Mud Gravel Mines Large Power Slurry Pump
Supply Capability:
1000
Lead time:
15days
Trade Terms:
Payment Terms :
TT in Advance
Certification :
Origin :
China
Ref Price
USD 100 /Sets
1 (Min. Order Quantity)
WN(Q) series is a new dredge pump developed by our company adopting advanced CAD technology, the dredge pump is widely used in cutter head dredger or other dredging equipments. The pump is horizontal single-stage single-suction cantilever structure. The double casing structure can guarantee long-term safe and reliable running.
| Type | CAPACITY | HEAD | SPEED | EFFICIENCY | NPSHr | INLET DIAMETER | OUTLET DIAMETER | MAX. DIAMETER OF FLOWD PARTICE |
| m3/h | m | rpm | % | m | mm | mm | mm | |
| 300WN (QQ) | 1800-2200 | 20-65 | 300-550 | 70-78 | <4 | 350 | 300 | 240 |
| 450WN (Q) | 3200-3800 | 20-67 | 250-550 | 70-78 | <4.5 | 600 | 450 | 240 |
| 500WN (Q) | 4500-5800 | 20-65 | 250-550 | 74-80 | <4.5 | 650 | 500 | 240 |
| 600WN (Q) | 5000-7000 | 20-650 | 250-550 | 74-80 | <4.5 | 660 | 600 | 250 |
| 650WN (Q) | 6000-9000 | 20-70 | 200-400 | 75-85 | <5.5 | 700 | 650 | 260 |
| 700WN(Q) | 7500-1200 | 20-75 | 200-400 | 78-85 | <5.5 | 760 | 700 | 280 |
| 800WN (Q) | 10000-15000 | 20-78 | 200- 380 | 80-84 | <6 | 900 | 800 | 300 |
| 900WN (Q) | 12000-19000 | 20-75 | 180-350 | 80-85 | <6 | 960 | 900 | 320 |
| 1000WN (Q) | 16000 - 25000 | 20-78 | 180-350 | 80-85 | <6 | 1000 | 1000 | 350 |
| Note:1.For detailed selection of flow rate, head, specific gravity, and equipped power, please consult us. |
