Making Machine for High Strength Corrugated Plastic Sheet Fiber FRP Panel Fiberglass Material Sheet
This machine can produce lighting sheet, color sheet, common flat sheet.
The raw materials used in frp sheet production machine are roving, unsaturated polyester resin, PET film, through roving and resin infiltration, heating curing molding, cooling shaping, physical cutting, to production of various frp sheets.
The machine stable operation, accurate control, continuous production of sheets for various application scenarios.
Machine function: This production line can produce corrugated roof sheet with color & transparent, common flat sheet, decorative sheet and so on. | |
Operation staff | 4-7 people |
Production speed | 2-10m/min |
Sheet width | maximum effective width of flat sheet is 1500mm |
Wave height | maximum 130mm |
Sheet thickness | 0.4mm-5mm |
Machine dimension | Normal 54m(L)×1.85(W)×3.5m(H), can be designed by customized |
Power requirement | 380V 50HZ 100KVA |
Power consumption | actual power consumption is about 25kw/h |
Packaging
After Sales Warranty
The machine is fully test before delivery, guarantee for 1 year excluding wear and electrical parts extra fee is paid if out of date. We will provide wear and electrical parts at an agency price when you need replacement.
