Scaffolding and formwork accessories Aluminum beams T225, Aluminum alloy 6061,6082

Brand
Cmax
Article No
3CFS0218146
Supplier ID
A01
Supply Capability:
4000LM/month
Lead time:
2 weeks
Trade Terms:
Ex UAE warehouse
Payment Terms :
Certification :
Conform to BS standard
Origin :
AE
Ref Price
AED 95.00 /Meter
500 (Min. Order Quantity)
Enquire Now Add to favorites

 Aluminium formwork beams with removable integrated wooden upper bar.

Reduced labour costs as working with lighter products requires less time and effort from operatives

Long life, as the aluminium can not be cut on site and is more resistant to falls and dents

High-strength aluminium alloy which can be recycled at no cost and enables high residual value

Lower transportation and storage costs due to the lightweight design.

The beam section has a multi-function track-shaped profile in the lower part that enables the connection of different accessories.

Weather resistant

Space saving and easy to store and transport in cages


Top and bottom wide:100mm
Bottom Wide:90mm
Height:225mm
Material:6005-T5; 6061-T6
Weight: 8.30kg/m
Tech Data:
Cross sectional  Area:  30.40CM2
Perimeter: 846.46mm
Moment of resistance xx axis: 25 kNm
Maximum reaction:  80kN
Shear rigidity xx axis (GA):35110kN
Modulus of elasticity (E): 69000N/mm2
Flexural rigidity xx axis (EI): 1468 kNm2


Packaging

Bundled by steel strips

After Sales Warranty

N/A
