Electric Multi-turn Actuated Gate Valve DS/Z44H

Brand
FRY
Article No
S12299213568
Supplier ID
S0060
Supply Capability:
300
Lead time:
15 DAYS
Trade Terms:
Payment Terms :
TT in Advance
Certification :
Origin :
Ref Price
RMB 300 /Sets
1 (Min. Order Quantity)
Enquire Now Add to favorites

                            Electric gate valve DS/Z44H


Product overview

The electric gate valve controls the opening and closing of the valve through the lifting of the gate. The gate is perpendicular to the fluid direction. The size of the passage can be changed by changing the relative position between the gate and the valve seat. The fluid resistance of the gate valve is small, the sealing surface is less brushed and corroded by the medium, the opening and closing is labor-saving, the flow direction of the medium is not restricted, the flow is not disturbed, the pressure is not reduced, the shape is simple, the structure length is short, the manufacturing process is good, and the scope of application wide.

Performance characteristics

1. The valve adopts pressure self-tightening seal or valve body and bonnet gasket seal structure, which is trustworthy! Safe and reliable to use.
2. The valve disc adopts a double gate with a universal top structure in the middle, which can automatically adjust the fit between the valve disc and the sealing surface of the valve seat to ensure the sealing of the valve. At the same time, this structure is convenient to maintain, save costs, and has better valve disc interchangeability.
3. The sealing surface of the valve disc and valve seat is made of cobalt-chromium-tungsten cemented carbide by plasma spray welding. The sealing surface has high hardness, abrasion resistance, abrasion resistance and long service life.
4. The valve stem is made of nitrided steel with surface nitriding treatment, high hardness, scratch resistance, corrosion resistance and long service life.
5. The electric device is equipped with a torque control mechanism, an on-site operating mechanism, and a hand and electric switching mechanism. In addition to local operation, remote operation, PLC control, 4-20mA current input and output intelligent control, etc. can also be carried out.
6. The manual valve is opened by the manual mechanism or the hand wheel upon impact. Reduce valve operating force.
7. The valve can be installed in any position of the pipeline, and the carbon steel or alloy steel valve can be selected according to the temperature of the medium and the medium. When installing and debugging for the first time, the valve must be manually opened to about half of the position to avoid damage to the valve or electrical equipment due to the reverse connection of the motor phase sequence.

Working temperature category:
(1) Ultra-low temperature valve: used for valves with medium working temperature t<-100°C.
(2) Cryogenic valve: a valve used for medium working temperature -100℃≤t≤-40℃.
(3) Normal temperature valve: the valve used for medium working temperature -40℃≤t≤120℃.
(4)Medium temperature valve: used for medium working temperature 120℃.
(5) High temperature valve: used for valves with medium working temperature t>450℃.

Mounting dimension drawing

.jpg

DS/Z44H-16C DS/Z44Y-16I DS/Z944H-16C DS/Z944Y-16I


More Products Display



Basic parameters

valve body

WCB

WC6/WC9

cap

WCB

12Cr1MoV

Stem

38CrMoAlA

25Cr2MoV

gate

25/WCB

WC6/WC9

bolt

B7

25Cr2MoV

Applicable medium

Water,gas,oil,etc.

Water,gas,oil,etc.

Maximum working temperature

425℃

550/590℃

Packaging
