Hydraulic Power Packs Bulldog power supply of breakers portable onsite power source generators

Advantages

• 12% more compact but with the same market leading performance.
• Small enough to be transported in estate cars and small vans.
• Tilt-back protection frame allows for simple routine maintenance.
• Clip & Go removeable, optional Tool Tray available to help store your Hydraulic Breaker and Breaker Steel.
• More powerful engine than standard market equivalent.
• Fully protected oil filler complete with retaining chain.
• Complete with integrated POD (Power On Demand) system which helps reduce carbon emissions & results in 50% less fuel usage.
• Recoil protection system.
• Low engine & hydraulic oil cut out protects tools & system pump.
• Rigid & durable steel chassis and protection frame to prevent component damage.
• Hose storage position and lifting-eye integrated into protection frame with fi tted wheels to aid on-site transportation.
• Supplied with removeable braided Siamese hose set with high quality non-drip face couplings (pre-fi lled with Hydraulic Oil).
• Removable hose sets aid transportation and storage and can be changed quickly if damaged.
• Can be used with Altrad Belle BHB 25X, BHB 27X, BHB 12, BHB 23, BHB 25 & BHB 27 Hydraulic Breakers and Hydraulic Submersible Pumps.
• Customer colour options available.

  Ref	Model	Engine  Power (hp/kW)	Hose Length (m)	Pressure (bar)	Flow (l/min)	Oil Tank Capacit (Ltr)	Fuel Tank Capacity (Ltr)	Width (mm)	Height (mm)	Length (mm)	Weight (kg)
  HPX01S	Bulldog Honda Petrol	9.0 / 6.6	6.75	140	20	5.6	6.0	515	620	705	59.5
  HPX01TS	Bulldog Honda Petrol c/w Tool Tray	9.0 / 6.6	6.75	140	20	5.6	6.0	683	320	705	59.5
